1 Clean water for the future Generations / tiszta vizet a jövő generációinak

2 Global Overview GE s portfolio structured for growth 8 businesses operating in more than 100 countries 125+ years >300,000 employees worldwide Power & Water Oil & Gas Energy Management Aviation Healthcare Transportation Home & Business Solutions GE Capital Thermal PG Services Renewables Aero derivatives Water Gas engines Nuclear Drilling & Surface Global Services Measurement & Control PII Pipeline Solutions Subsea Systems Turbo machinery Digital Energy Power Conversion Industrial Systems Commercial Military Service Avionics/ Systems Healthcare Systems Life Sciences Healthcare IT Molecular Diagnostics Locomotives Services Propulsion Systems Appliances Lighting Intelligent Platforms Commercial Consumer Real Estate GECAS EFS

3 Quick Facts Headquartered in Trevose, PA, USA 7,900 employees globally 50,000 customers in 130 countries 50 global manufacturing sites Water & Process Technologies Aligning the best people with the most advanced technology, products and services to solve any water or process challenge our customers may have

4 Expertise and innovation Acquisition 1999: Glegg Water Conditioning 2002: BetzDearborn 2003: Osmonics, Inc. 2005: Ionics 2006: ZENON Environmental Innovation 2007: GE launches TrueSense 2008: GE launches GenGard 2009: GE launches the Muni.Z depth filter using Z.Plex technology, PROPAK system, and ZeeWeed : GE launches Mobile Evaporator, Mobile M-PAK, HERO and ZCore 2011: GE launches LEAPmbr and SeaPAK Expansion 2009: The GE/NUS Singapore Technology Center opens 2009: GE opens Water & Process Technology Center in Saudi Arabia 2011: Wuxi plant expansion doubles capacity of water technology manufacturing in China : Tripled capacity at Oroszlány, Hungary production site 2012: Opening of new laboratory in Cotia, Brazil 2013: GE Water and Process Technologies legal entity change 4 Water & Process Technologies

5 Mobil ProPak45 állomás

6 Water & Process Technologies Hungary Oroszlány I Tatabánya

7 Site Established in 2002 Total Land Area ~ m 2 Total site employees 755 Phase m2 Hall & 2*1500m2 Office 2002 Phase m2 Hall 2004 Phase m2 Hall & 2*240m2 Office 2006 Clean water for the Future Generations We provide clean water around the globe as the world s largest UF/MBR membrane module manufacturing site in the industry We are the Central Eastern Europe Centre of Excellence for the GE Water & Process Technologies Engineered Systems business We are empowered to become global experts through our local know-how, continuous learning and professionalism We are a great team, working together for a great company RO Hall 1100m2 Hall & Office 2008 WWTP & Lab 2008

8 Global Water Challenges and answers by GE Power & Water

9 Market & Regulatory Drivers Megatrends Climate Change Population Growth/ The Multispeed World + + Unconventional O&G/ The Age of Gas Water-related Issues Water Scarcity Natural Disasters Water Quality Trade / Globalization Energy Demand & Supply Industry Needs Reuse Efficiency Resource Recovery Alternative Sources Resilient Systems Innovative Technologies Low Cost Energy GE Company Proprietary & Confidential GE 2014 All Rights Reserved 9

10 The Energy Water Nexus Water-related needs for energy production have tripled since 1995 Roughly 75% of all industrial water withdrawals are used for energy production Energy consumption at water and wastewater utilities is projected to grow by more than 20% by 2027 Energy use is projected to increase ~50% by 2030 and demand for water by ~50% Source: IEA Database 2010 Due to demand grow there is a growing competition over natural resources, WEF is an attempt to balance different uses of ecosystem resources GE Company Proprietary & Confidential GE 2014 All Rights Reserved 1

11 GE s water reuse technology spectrum GE Water reuse technologies as a function of the % of reuse/recycle & complexity GE Company Proprietary & Confidential GE 2014 All Rights Reserved

12 Product Portfolio ZeeWeed 500 Module ZeeWeed 1000 Module ZeeWeed 1500 Module Supported Membran fiber Unsupported Membran fiber Unsupported Membran fiber 2 Chemistries 31 Modules 56 SKUs 2 Chemistries 4 Modules 50 SKUs 1 Chemistries 1 Modules 1 SKUs RO element Element rolling 2 Chemistries 18 Modules 18 SKUs

13 Need for innovation reuse via tech advancements Existing Solutions Combined Solutions Enable higher reuse of wastewater and reduce operating costs LEAP MBR Mobile Solutions Simplify your design by reducing membrane aeration equipment and controls by 50%. Reduce your operating costs with a 30% energy savings. Have the confidence of the strongest, most reliable membrane in the industry. Potential to reduce operating costs by 40% GE ZLD Solutions GE ZLD systems offer 95% availability and are up to 30 percent more energy efficient than conventional designs. These technologies can often be combined with other GE equipment, such as ultrafiltration (UF), reverse osmosis (RO), electrodeionization (EDI) and ion exchange to provide the optimal solution. GE Company Proprietary & Confidential GE 2014 All Rights Reserved

14 Wastewater treatment accounts for 3% of the electrical load in the US EPA Office of Water. Wastewater Management Fact Sheet, Energy Conservation, EPA 832-F , July The future: Energy neutrality GE Company Proprietary & Confidential GE 2014 All Rights Reserved

15 Energy neutral wastewater treatment ZeeLung Membrane Aerated Biofilm Reactor (MABR) 4X savings in energy consumption for treatment Monsal Advanced anaerobic digestion Biogas production from sewage sludge & organics Jenbacher CHP gas engine Electricity generation from biogas Energy neutral aspiration is enabled by GE Power & Water portfolio GE Company Proprietary & Confidential GE 2014 All Rights Reserved 15

16 A new energy neutral wwtp flow sheet Optimize shunt of organics to sludge treatment; minimize organic load to biological treatment Reliable N removal using proven nitrification-denitrification; Maximize oxygen transfer efficiency ZeeLung (MABR) ZeeWeed (MBR) Anaerobic digestion for generation of biogas Energy (electricity, heat) from biogas with high efficiency CHP Energy-neutrality is the most disruptive product launch in the next decade GE Company Proprietary & Confidential GE 2014 All Rights Reserved

17 Global Case Studies

18 Új vízforrás létrehozása Kuwait-ban Kihívás: Öntözésre és emberi fogyasztásra elégtelen vízminőség Megoldás: Víztisztítás öntözésre, édesvíz felszabadítása ivásra Sulaibiya telep - Kuwait City Víz előállítása öntözésre Felszabadít édesvizet emberi fogyasztásra 375,000 köbméter/nap A világ legnagyobb membrán alapú szennyvízszűrő projektje

19 Új élet a régi infrastruktúrának Kihívás: Meglévő hagyományos technológia kapacitás limit Megoldás: Technológia cseréje LEAP UF MBR-ra Brescia önkormányzati szennyvíz - Olaszország 4x-es kapacitás növekedés az ultraszűréssel ugyanolyan alapterületű helyen 2,5 millió liter/nap folyamatos áramlás Ipari szennyvízminőség drámaian javult az új szennyvíz szabályozásoknak megfelelően Felváltotta a hagyományos technológiát

20 NEWater Szingapúrban Kihívás: Nem megfelelő megújuló édesvíz ellátás Megoldás: Helyi ipari szennyvízkezelés és újrahasznosítás Bedok NEWater Gyár Szennyvíz átalakítása magas minőségű ipari tápvízzé és ivóvízzé A végtermék neve NEWater Eleinte az elektronikai ipar, ostyagyárak és keresekedelmi épület hűtőtornyok használták tápvízként, Nagyrészüket visszaengedik a helyi víztározóba indirekt ivóvíz újrahasznosító alkalmazásokra

21 Henriksdal Project (Stockholm) Kihívás: Megrendelés nagysága + projekt helyszine Megoldás: LEAP MBR technológia Design criteria: people by year 2040 Maximum flow, 19 m³/s, cca m3/d Maximum flow to biological treatment and membranes, 10 m³/s Excuted in 4 phases within Phase 1 144pcs ZW500d, Phase pcs ZW500D/phase 21

22 Local water & energy saving projects

23 Hővisszannyerés technológiai összegzése UFMBR gyártócsarnok Technológiai melegvíz 148m3/h 3440kW 60/80 C Szennyvíz hűtés m3/nap 40 C ->25 C Szennyvíztelep

24 Szennyvíz újrahasznosítása ProPak45 rendszer Megvalósítás GE UFMBR és Propak UF, RO mobil szűrő állomás segítségével, Oroszlányban előállított membránelemeken keresztül.

25 Környezetvédelmi díjaink GE Ecomagination Nation Bronz Award 2012 December GE Ecomagination Nation Silver Award 2014 Május KÖVET Környezeti megtakarítási díj Legízletesebb alacsonyan csüngő gyümölcs kategória 2014 November GE ecowaters Award 2014 December 25
